Evaluating carbon sequestration

Deforestation and land degradation have hugely impacted the planet’s natural ability to remove atmospheric carbon dioxide. Projects to restore the balance are well underway, but quantifying their success
is difficult, calling for a new multidisciplinary analytical approach

14th September 2016

A satellite image of South Kalimantan, Indonesia.
False-colour images in infrared provide detailed information on vegetation, such as plant type and health – brighter red indicates thicker vegetation.  © JAXA/ESA

Evaluating carbon sequestration

Deforestation and land degradation have hugely impacted the planet’s natural ability to remove atmospheric carbon dioxide. Projects to restore the balance are well underway, but quantifying their success
is difficult, calling for a new multidisciplinary analytical approach

By Geeta Batra , Chief Evaluation Officer, Independent Evaluation Office, Global Environment Facility and Juha I. Uitto , Director, Independent Evaluation Office, Global Environment Facility

Much effort is being devoted to evaluating the impacts of aid and investment projects on the rate of loss of tropical forests, and the related climate benefits, in the Americas, Africa and Asia, using satellite-based measures of forest cover. Despite these efforts, the valuation of the benefits accruing from avoided losses – i.e. standing forests and concomitant carbon sequestration – is relatively unknown.

Multidisciplinary approach
What is known is that avoiding deforestation is an economically attractive option, as it is one of the cheapest ways of reducing emissions, in terms of dollars per tonne of carbon.1 Applying a multidisciplinary approach, with a diverse set of tools, provides a better understanding of the drivers of degradation, and the valuation of benefits. This approach is currently being utilised in the context of the Global Environment Facility (GEF).

To determine the extent of carbon sequestration, we employ a variety of geospatial and statistical tools to assess the factors influencing the outcomes of the GEF-funded programme in land degradation.2

The land degradation focal area is the window that supports efforts by countries eligible for GEF support to combat land degradation, specifically desertification and deforestation in rural production landscapes. This investment relates directly to the GEF’s role as a financial mechanism of the United Nations Convention to Combat Desertification.

Forests contribute significantly to
carbon sequestration through holding
large carbon stocks. When forests are cut, they can no longer hold the carbon, thus having an impact on climate change. Carbon stocks cannot be observed directly from satellite imagery. However, they can be estimated through examining factors associated with carbon stocks, particularly vegetation biomass.

The normalised difference vegetation index (NDVI) is one of the most widely used vegetation indices to estimate carbon stocks. To date, empirical studies employing remote sensing to estimate carbon storage have done so at a local or country level and have shown that NDVI can strongly predict the extent of carbon stocks.

We quantify the causally identified impact attributable to GEF projects along four dimensions (vegetation productivity; forest fragmentation; carbon stocks and sequestration; and land cover change), using satellite outcome measurements. We employ propensity score matching methods to examine the impact of GEF projects, and related geographic heterogeneity, on these four impacts.

Other data integrated into the analysis include long-term climate data, population data, distance to rivers, distance to roads and night-time lights, to account for socio-economic differences in locations.

The analysis covers the entire GEF land degradation portfolio: altogether some 200 projects and approximately 450 locations. The projects were geocoded and are fairly heterogeneous in terms of their scope, design and geographical location. They are mostly located in areas with a relatively low population density and level of electrification. The physical geographic characteristics of the project locations are highly variable in terms of temperature, precipitation, elevation and slope, and not all the projects are located in areas that have forest cover.

Evaluating impact
Classification and regression-tree approaches3 have been commonly employed over the last two decades to aid in the classification of remotely sensed imagery. They can be used to identify causal effects of an intervention. Based on these approaches, we have found that, in
general, GEF projects have had a positive impact on NDVI, forest cover and reduction in forest fragmentation, with variation in the estimated range of impacts across countries.

We were also able to detect certain determinants that explain the relative success of the projects. Those projects with relatively longer durations performed better, and environmental (slope, elevation, temperature, precipitation) and social (population density, urban distance) characteristics all proved important in mediating the impact of the projects.

There is some evidence that projects closer to urban areas were slightly more successful in mitigating forest cover losses. Projects were also heavily influenced by the initial state of forest fragmentation – i.e. the pre-trend of average forest size is an important factor in determining the heterogeneity in project impacts.

Based on the analysis of GEF-funded projects, relatively higher levels of carbon sequestration have been observed in Senegal, southern Niger, Kyrgyzstan and Vietnam.

Methodological limitations
Understanding the factors that influence the various impacts is a first step. Quantifying the tonnes of carbon sequestered, and assessing the corresponding value that is directly attributable to the interventions, is challenging but now well within reach, thanks to this multidisciplinary approach.

Examining the causal impact of these interventions on environmental outcomes has been a central goal of the multilateral agencies but there has hitherto been limited engagement in using spatially explicit, geocoded aid information due to limitations in both data and methods.

These methodological limitations primarily stem from distinctions between modelling efforts seeking to predict relationships commonly taught and accepted by the geographic community (i.e. spatial regression or classification trees), and efforts that seek to establish causal relationships similarly taught and accepted by the economics community (i.e. propensity score matching or difference-in-difference modelling).

Recently, efforts have been undertaken to merge these disciplinary approaches to explain the impacts of these interventions, of which this analysis provides an example. This integrated approach to evaluation and research provides a promising avenue towards better quantification of climate benefits from reduced land degradation and deforestation.

  1. TEEB. The Economics of Ecosystems and Biodiversity: Mainstreaming the Economics of Nature: A Synthesis of the Approach, Conclusions and Recommendations of TEEB. 2010.
  2. This paper draws on ongoing methodological research being carried out by the Independent Evaluation Office of the GEF and AidData: “Value for Money in Land Degradation Projects of the GEF.” 2016, forthcoming.
  3. Classification and regression trees are machine-learning methods for constructing prediction models from data.
